Water Soluble Film Small Sachets Powder Packing Machine

Water Soluble Film Small Sachets Powder Packing Machine

  • Water Soluble Film Small Sachets Powder Packing Machine
  • Water Soluble Film Small Sachets Powder Packing Machine
  • Water Soluble Film Small Sachets Powder Packing Machine
Water Soluble Film Small Sachets Powder Packing Machine
Product Details:
Place of Origin: China
Brand Name: OEM
Certification: CE ISO
Payment & Shipping Terms:
Minimum Order Quantity: 1 Set
Price: Negotiation
Packaging Details: wooden case package
Delivery Time: 15-20 Days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 30 Sets per Month
Contact Now
Detailed Product Description
Name: Powder Packing Machine Packaging Film: Water-Soluble Film
Shape Of Bag: Sachet,Pillow Bag Machine Made Of: Stainless Steel
Powder Dosing: Auger Filler Packing Speed: 5-50 Bags/Min
Highlight:

Small Sachets Powder Packing Machine

,

Sachets Powder Pouch Packing Machine

,

800ML Powder Pouch Packing Machine

Water Soluble Film Small Sachets Powder Packing Machine





Application



This packing machine is New Design special for the Water soluble film packing machine ,widely used to pack powder products,chemical and medical powder products etc.



Technical characteristics



1: PLC control the machine and most of operate bycolor touch screen. bag-making, measuring, filling, printing,cutting , all in one.

2: Film-Running by servo motor and double belt, bag is formed in good shape.



Main Features:



  • Stainless Steel construction (SS304)
  • PLC Servo and Pneumatic control system
  • Intuitive operation and easy to use software through a SIEMES /SCHNIDER Brand Color Touchscreen HMI
  • SIEMESN OR SCHNIDER Brand PLC
  • Film tracking byhigh precision photo sensor



Parameters



Packing Speed 5-50 Bags/Min
Volume 800ML
Bag Width 20 -150 mm
Bag Length 80 – 240mm
Bag Type Pillow Bag/Center seal
Packaging Film Max Width 320MM
Packaging Film Thickness 0.04-0.09MM
Packaging Film Material Water-Soluble Film
Weight 350KG
Air Consumption 0.5m³/Min
Air Pressure 6-8 Kg/m
Power Supply 220VAC/50-60Hz
Power 2.2Kw
Dimension LxWxH (L)1170x(W)820x(H)1285MM



Water Soluble Film Small Sachets Powder Packing Machine 0

Water Soluble Film Small Sachets Powder Packing Machine 1
